STA-2x3000 Touring Amplifier
Model code: YB-STA2X3000
A 2 x 3000 W touring amplifier with Dante ready inputs and front panel fault logging for rental fleets.
- 2 x 1800 W into 8 Ohm, 2 x 3000 W into 4 Ohm, 6000 W bridged
- Neutrik speakON outputs and a Dante option card slot
- Four speed fan with front to rear airflow
- Full protection suite with front panel fault logging
Ships in 5-7 business days
Technical specifications
Output
- Channels
- 2
- Amplifier class
- Class D
- Power per channel at 8 Ohm
- 1800 W
- Power per channel at 4 Ohm
- 3000 W
- Bridged output
- 6000 W
Measured performance
- THD + N
- 0.1 %
- Signal to noise ratio
- 102 dB
- Damping factor
- 500
- Frequency response
- 10 Hz - 30 kHz (+0 / -1 dB)
Connectivity
- Input sensitivity
- 1.4 V / 2.8 V selectable
- Input impedance
- 20 kOhm balanced
- Inputs
- 2x XLR balanced, Dante option card slot
- Outputs
- 2x speakON NL4
Mechanical
- Cooling
- Four speed fan, front to rear
- Protection
- Clip limiter, thermal, DC, short circuit, VHF, mains dip
- Rack height
- 2 U
- Dimensions
- 483 x 88 x 460 mm
- Net weight
- 18.5 kg
Overview
STA-2x3000 Touring Amplifier
The STA-2x3000 is a touring amplifier built for rental inventories. The chassis is 2 U, the front panel is recessed and the airflow is front to rear so racks can be stacked tightly.
Fault logging on the front panel records the last eight events with time stamps, which makes it possible to see whether a channel shut down because of a thermal event, a short circuit or a mains dip.
