HFA-D200 Integrated Amplifier
Model code: YB-HFAD200
Compact Class D integrated amplifier with five inputs, 2 x 200 W and a subwoofer output with an 80 Hz high pass.
- Class D output stage with a 2 x 200 W rating into 8 Ohm
- Optical, coaxial, USB-B, RCA and XLR inputs
- Subwoofer output with a switchable 80 Hz high pass
- 2 U chassis, 6.4 kg, convection cooled
Ships in 2 business days
Technical specifications
Output
- Channels
- 2
- Amplifier class
- Class D
- Power per channel at 8 Ohm
- 200 W
- Power per channel at 4 Ohm
- 350 W
- Bridged output
- 700 W
Measured performance
- THD + N
- 0.008 %
- Signal to noise ratio
- 108 dB
- Damping factor
- 180
- Frequency response
- 10 Hz - 40 kHz (+0 / -1 dB)
Connectivity
- Input sensitivity
- 0.9 V for rated output
- Input impedance
- 22 kOhm unbalanced / 44 kOhm balanced
- Inputs
- 1x optical, 1x coaxial, 1x USB-B, 2x RCA, 1x XLR
- Outputs
- Binding posts, 1x subwoofer out
Mechanical
- Cooling
- Passive convection, no fan
- Protection
- Over-current, over-temperature, DC offset
- Rack height
- 2 U
- Dimensions
- 440 x 88 x 320 mm
- Net weight
- 6.4 kg
Overview
HFA-D200 Integrated Amplifier
The HFA-D200 is a compact Class D integrated amplifier for desks, studios and second systems. A 300 W switching supply feeds the output stage directly and stays above 90 percent efficiency at normal listening levels.
Five inputs cover optical, coaxial, USB-B, RCA and XLR sources. The subwoofer output carries a switchable 80 Hz high pass so small monitors can be crossed over without an external processor.
