PAA-2x1600 Power Amplifier
Model code: YB-PAA2X1600
Two channel Class D amplifier with a power factor corrected supply and 3200 W bridged output for subwoofers.
- 2 x 950 W into 8 Ohm, 2 x 1600 W into 4 Ohm, 3200 W bridged
- Power factor corrected supply that runs on 100-240 V
- Binding post and speakON outputs on every channel
- DSP ready with an optional 96 kHz module
Ships in 5-7 business days
Technical specifications
Output
- Channels
- 2
- Amplifier class
- Class D
- Power per channel at 8 Ohm
- 950 W
- Power per channel at 4 Ohm
- 1600 W
- Bridged output
- 3200 W
Measured performance
- THD + N
- 0.05 %
- Signal to noise ratio
- 104 dB
- Damping factor
- 350
- Frequency response
- 15 Hz - 25 kHz (+0 / -1 dB)
Connectivity
- Input sensitivity
- 1.4 V for rated output
- Input impedance
- 20 kOhm balanced
- Inputs
- 2x XLR balanced with link out
- Outputs
- 2x speakON NL4, binding posts
Mechanical
- Cooling
- Variable speed double fan, front to rear
- Protection
- Clip limiter, thermal, DC, short circuit, VHF
- Rack height
- 2 U
- Dimensions
- 483 x 88 x 420 mm
- Net weight
- 14.2 kg
Overview
PAA-2x1600 Power Amplifier
The PAA-2x1600 is a two channel Class D amplifier for subwoofers and high output full range systems. The power factor corrected supply draws a clean sine current, which matters on generators and long cable runs.
A 96 kHz DSP module can be fitted later for crossovers, limiters and delay without changing the amplifier.
