PAA-4x800 Installation Amplifier
Model code: YB-PAA4X800
Four channel Class D installation amplifier, 1 U tall, with 70 / 100 V constant voltage mode on every output.
- Four channels of 480 W into 8 Ohm or 800 W into 4 Ohm
- 1 U chassis with front to rear cooling and speakON outputs
- Switchable 0.775 V / 1.4 V input sensitivity
- Selectable 70 V and 100 V constant voltage mode
Ships in 5-7 business days
Technical specifications
Output
- Channels
- 4
- Amplifier class
- Class D
- Power per channel at 8 Ohm
- 480 W
- Power per channel at 4 Ohm
- 800 W
- Bridged output
- 1600 W
Measured performance
- THD + N
- 0.02 %
- Signal to noise ratio
- 106 dB
- Damping factor
- 400
- Frequency response
- 20 Hz - 20 kHz (+0 / -0.5 dB)
Connectivity
- Input sensitivity
- 0.775 V / 1.4 V selectable
- Input impedance
- 20 kOhm balanced
- Inputs
- 3x XLR balanced with link out
- Outputs
- 4x speakON NL4
Mechanical
- Cooling
- Two temperature controlled fans, front to rear
- Protection
- Clip limiter, thermal, DC, short circuit, VHF
- Rack height
- 1 U
- Dimensions
- 483 x 44 x 380 mm
- Net weight
- 9.6 kg
Overview
PAA-4x800 Installation Amplifier
The PAA-4x800 is a four channel Class D amplifier for fixed installation. It fits in 1 U and can drive either low impedance loudspeakers or 70 / 100 V distributed lines on every channel.
Each channel has its own clip limiter and thermal monitor, so a fault on one output does not affect the others. Inputs are electronically balanced on XLR with link outputs for daisy chaining.
